x-change® fresh
Highly efficient domestic water heat pump for sustainable, resource-efficient domestic water heating.
The x-change fresh heat pump uses the air (room, extract, or outside air) to heat domestic water. It has a storage capacity of 258 litres and can generate up to 850 litres of hot water in 24 hours. The water is heated to temperatures of up to 62 °C. It is an ideal addition to a solar panel system. Due to the Power-to-Heat principle, some of the self-generated electricity can be used to operate the x-change fresh pump. The highly efficient domestic water heat pump with a COP value of 2.98 (A15/W55) is ideally for this operating mode.
System benefits
Heat pump energy efficiency class A+++
Safety capacitor, no calcification of the capacitor
Ø 160 mm duct connections for extract or outside air operation
2-speed fan operation
Integrated heat exchanger for solar thermal energy or other heat generators
258-litre glazed steel tank with magnesium anode
Power to Heat*: intelligent use of excess solar-generated electricity
Polyurethane rigid foam insulation
Maximum operating pressure 10 bar
Integrated defrosting with hot gas
Integrated 2 kW screw-in radiator
Thermal disinfection (anti-legionella bacteria heating program)
Use of own solar-generated electricity possible
Technical data
| Energy source | Air |
| Installation site | Inside |
| Function | Domestic water heating |
| Power output (kW) | 1.4 (for A15/W55) |
| COP (tested in compliance with EN 14511:2011) | 3.61 (for A20/W53) |
| Height / diameter (mm) | 1768 / 707 |
| SG-ready (in conjunction with Kermi Energy Manager) | Yes |
| Energy efficiency class | A+ |
