Electrical solutions

The WRX variant comprises a wall outlet (protection type IPX4) including a radio receiver, an electrically regulated heating rod (not provided with infrared radiators), and a radio controller. The radio controller is equipped with a touch display which can be used to program and control various functions. The controller can be surface-mounted anywhere in the room as it is battery-operated. The wall outlet is mounted on a flush-mounted box.

• Room temperature control for heating and low setting levels at programmed time intervals
  - Programmable time interval: 15 minutes
  - 2 preset, 1 freely programmable weekly programme (room temperature)
• Presence/absence mode
• Open window detection
• Controller available in White/White, Black/Black, or White/Black (housing/display), wall outlet always in White

Wall Radio Standard (WRS) controller

The controller consists of a wall outlet including a radio receiver, an electronically controlled heating rod and the WRS controller. The battery operation means that the controller can be installed anywhere in the room.

• Large 7-segment LED display with full-surface glass front and four touch-sensitive buttons
• Set temperature input possible in 0.5 increments
• Boost mode (60 minutes full load)
• Frost protection function
• Radio thermostat – batteries included in scope of delivery
• Option to switch from room temperature control to towel warmer function in the controller settings menu
• Available in white (similar to RAL 9003) or black (similar to RAL 9017)
• Ecodesign-compliant thanks to open window detection and daily/weekly programme planning directly on the controller
• Control of up to 8 radiators with one controller
• Radiator with heating element or heating mat can be controlled
• The room control unit is limited to the function on/off, changing the setpoint temperature/heating level and boost. (Hotel mode)
• Size: 110 mm x 95 mm x 20 mm (WxHxD)

Wall Wired Standard (WWS) controller

The controller consists of a wall outlet, an electronically controlled heating rod and the WWS controller. The controller and wall outlet are connected by means of a conduit pipe.

• Large 7-segment LED display with full glass front and four touch-sensitive buttons.
• Frost protection function.
• Option to switch from room temperature control to towel warmer function in the controller's settings menu.
• Available in white (similar to RAL 9003) or black (similar to RAL 9017).
• Cable length approx. 1.2 m; can be shortened by the customer without voiding the warranty.
• Ecodesign-compliant through open window detection and day-specific weekly programme planning directly on the controller.
• Radiators can be controlled with a heating rod or heating mat.
• The controller and wall outlet are connected by means of a conduit pipe.
• The room control unit is limited to the on/off function, changing the setpoint temperature/heating level and boost. (Hotel mode)
• Dimensions: 110 mm x 95 mm x 20 mm (WxHxD)

The FKS variant comprises an electronically regulated heating rod including a controller (protection type IPX4) that is installed on the radiator. The length of the heating rod cable is approximately 1.2 m. The controller is available in White and Chrome Silver.

• Continuously variable temperature control
• Boost mode (full capacity for 60 minutes)
• Antifreeze protection
• Function display (Heat, Off, Booster)
• During commissioning, it is possible to switch from room temperature control to a towel warming function only
• Available in White and Chrome Silver
